ACTEL A2F500M3G-1CSG288I
- SmartFusion cSoC integrating FPGA fabric, ARM Cortex-M3 processor, and programmable analog
- 500,000 equivalent gates with 11,520 logic cells
- 130nm flash-based process technology at 1.5V core voltage
- Operating frequency up to 100 MHz
- 288-pin CSP BGA package (TFBGA) for compact board designs
- Industrial-grade temperature range: –40°C to +85°C
The ACTEL A2F500M3G-1CSG288I is a SmartFusion Customizable System-on-Chip (cSoC) from Actel (Microsemi / Microchip), combining three powerful technologies on a single device: a 500K-gate FPGA fabric, a hardened ARM Cortex-M3 processor, and programmable analog circuitry. Built on a 130nm flash-based process at 1.5V, it delivers a highly integrated, low-power solution that eliminates the need for discrete microcontrollers, FPGAs, and analog components on the board. The "-1CSG288I" suffix denotes the standard speed grade, 288-pin CSP BGA package, and industrial temperature rating.
Unlike conventional FPGAs, the ACTEL A2F500M3G-1CSG288I offers a complete embedded system platform in a single chip. The hardened ARM Cortex-M3 core operates independently from the FPGA fabric, enabling parallel processing of control and logic tasks. Its programmable analog block supports ADCs, DACs, and analog signal conditioning, making the ACTEL A2F500M3G-1CSG288I an ideal choice for mixed-signal embedded designs across industrial, communications, and smart energy applications.
Related Products For Your Business
What Is the ACTEL A2F500M3G-1CSG288I SmartFusion cSoC?
We are a trusted supplier of the ACTEL A2F500M3G-1CSG288I SmartFusion cSoC. We source the ACTEL A2F500M3G-1CSG288I with full traceability and rigorous quality inspection to meet the demands of industrial, communications, and embedded system procurement worldwide. The ACTEL A2F500M3G-1CSG288I is a uniquely integrated device that combines an FPGA, a hardened ARM Cortex-M3 processor, and programmable analog circuitry on a single chip.
ACTEL A2F500M3G-1CSG288I FPGA Architecture: 500K Gates on 130nm Flash Process
The ACTEL A2F500M3G-1CSG288I is built on Actel’s 130nm flash-based CMOS process, delivering 500,000 equivalent gates and 11,520 logic cells operating at up to 100 MHz. Its flash-based architecture is non-volatile and retains configuration after power-off without the need for an external boot device. The ACTEL A2F500M3G-1CSG288I includes 512 KB of on-chip flash memory and 64 KB of SRAM, fully accessible by the hardened ARM Cortex-M3 processor core.
ACTEL A2F500M3G-1CSG288I Package: 288-Pin CSP BGA for High-Density Designs
The ACTEL A2F500M3G-1CSG288I is housed in a compact 288-pin CSP BGA (TFBGA) package, enabling high-density PCB designs with a minimal footprint. By integrating FPGA logic, an ARM processor, and programmable analog in a single device, the ACTEL A2F500M3G-1CSG288I significantly reduces board space, component count, and system power consumption compared to traditional multi-chip solutions.
Why Choose the ACTEL A2F500M3G-1CSG288I for Industrial and Embedded Applications?
The ACTEL A2F500M3G-1CSG288I is rated for industrial temperature operation from –40°C to +85°C, making it reliable across a wide range of operating environments. Its RoHS-compliant, lead-free packaging supports modern manufacturing requirements. The ACTEL A2F500M3G-1CSG288I is supported by Actel’s Libero IDE design software, providing a complete development environment for FPGA logic design and ARM firmware development.
- The ACTEL A2F500M3G-1CSG288I integrates FPGA fabric, ARM Cortex-M3, and programmable analog on a single chip.
- It delivers 500,000 equivalent gates and 11,520 logic cells operating at up to 100 MHz.
- The ACTEL A2F500M3G-1CSG288I uses a 130nm flash-based process — non-volatile and boot-device-free.
- On-chip resources include 512 KB flash and 64 KB SRAM for embedded firmware storage and execution.
- Its 288-pin CSP BGA package enables compact, high-density board designs.
- The ACTEL A2F500M3G-1CSG288I operates across an industrial temperature range of –40°C to +85°C.
- Programmable analog blocks support on-chip ADC, DAC, and analog signal conditioning functions.
- RoHS-compliant and lead-free construction meets modern environmental standards.
- Full development support is available via Actel Libero IDE design tools.
- Urgent orders and long-term supply agreements for the ACTEL A2F500M3G-1CSG288I are available upon request.
