ACTEL A54SX72A-CQ208B
- HiRel SX-A antifuse FPGA with 72,000 equivalent system gates and 4,024 logic cells
- 0.22µm / 0.25µm CMOS antifuse technology — one-time programmable, non-volatile
- Standard speed grade operation in 208-pin ceramic QFP hermetic package
- 2.5V core with 2.5V, 3.3V, and 5V mixed-voltage I/O support
- FuseLock anti-tamper security technology for IP protection
- Military temperature range: –55°C to +125°C (B-grade)
The ACTEL A54SX72A-CQ208B is a HiRel SX-A family antifuse-based Field Programmable Gate Array (FPGA) from Actel (Microsemi / Microchip), offering 72,000 equivalent system gates and 4,024 logic cells on a 0.22µm / 0.25µm CMOS antifuse process. The "CQ208B" suffix identifies the 208-pin ceramic QFP hermetic package and military B-grade temperature rating of –55°C to +125°C. As a HiRel device without a speed grade suffix, the A54SX72A-CQ208B operates at the standard speed grade, making it a cost-effective option for military and aerospace designs where the highest frequency performance is not required.
Unlike reprogrammable FPGAs, the ACTEL A54SX72A-CQ208B uses one-time programmable antifuse technology, making it inherently immune to configuration upset, reverse engineering, and unauthorized modification. It supports mixed-voltage I/O operation at 2.5V, 3.3V, and 5V — including 66 MHz PCI compliance — with hot-swap compliant I/Os and individual output slew rate control. Actel's FuseLock security technology permanently prevents internal probing and design theft, making the ACTEL A54SX72A-CQ208B the trusted choice for classified and defense-grade logic designs.
Related Products For Your Business
The ACTEL A54SX72A-CQ208B is a HiRel SX-A family antifuse FPGA from Actel (Microsemi / Microchip), offering 72,000 equivalent system gates in a 208-pin ceramic QFP hermetic package, qualified for military B-grade operation from –55°C to +125°C. Built on 0.22µm / 0.25µm CMOS antifuse technology with FuseLock security, it is purpose-built for demanding defense, aerospace, and high-reliability applications at a standard speed grade.
ACTEL A54SX72A-CQ208B Architecture: HiRel SX-A Antifuse Technology
The ACTEL A54SX72A-CQ208B is built on Actel’s 0.22µm / 0.25µm CMOS antifuse process, delivering 72,000 equivalent system gates and 4,024 logic cells in a secure, one-time programmable architecture. Its antifuse interconnects are permanently programmed and cannot be erased, reconfigured, or read back — providing inherent protection against configuration upset and intellectual property theft. The ACTEL A54SX72A-CQ208B features deterministic, user-controllable timing and up to 100% resource utilization, enabling highly optimized logic implementations for performance-critical designs.
ACTEL A54SX72A-CQ208B Package: 208-Pin Ceramic CQFP for Military Environments
The ACTEL A54SX72A-CQ208B is housed in a 208-pin ceramic quad flat pack (CQFP) hermetic package, providing maximum protection against moisture, vibration, thermal shock, and chemical exposure in military-grade operating environments. Its hermetic ceramic construction meets the stringent reliability requirements of MIL-spec and aerospace programs. The ACTEL A54SX72A-CQ208B supports mixed-voltage I/O at 2.5V, 3.3V, and 5V, with 66 MHz PCI compliance and hot-swap compliant I/Os for flexible system integration.
Why Choose the ACTEL A54SX72A-CQ208B for Defense and Aerospace Applications?
The ACTEL A54SX72A-CQ208B is rated for military B-grade operation from –55°C to +125°C, making it reliable across the full temperature range encountered in airborne, shipboard, and ground-based military platforms. Actel’s FuseLock security technology permanently disables internal probing and prevents reverse engineering of the programmed design. As the standard speed grade variant of the SX-A 72K family, the ACTEL A54SX72A-CQ208B offers an economical solution for military designs where maximum operating frequency is not a primary requirement. Contact us today to request a quote and check availability for the ACTEL A54SX72A-CQ208B.
- The ACTEL A54SX72A-CQ208B offers 72,000 equivalent system gates and 4,024 logic cells on 0.22µm / 0.25µm CMOS antifuse process.
- Standard speed grade operation suits military designs where maximum frequency is not the primary requirement.
- One-time programmable antifuse architecture is immune to configuration upset and reverse engineering.
- FuseLock security technology permanently prevents internal probing and design theft.
- 208-pin ceramic CQFP hermetic package ensures reliable operation in harsh military environments.
- Mixed-voltage I/O support for 2.5V, 3.3V, and 5V with 66 MHz PCI compliance.
- Hot-swap compliant I/Os with individual output slew rate control for flexible system interfacing.
- JTAG boundary scan (IEEE 1149.1) compliance enables comprehensive in-system testing.
- Military B-grade temperature rating of –55°C to +125°C for full military environment operation.
- Urgent orders and long-term supply agreements for the ACTEL A54SX72A-CQ208B are available upon request.
Frequently Asked Questions (FAQ)
What Is the ACTEL A54SX72A-CQ208B and What Does It Do?
The ACTEL A54SX72A-CQ208B is a HiRel SX-A family antifuse FPGA offering 72,000 equivalent system gates at standard speed grade, housed in a 208-pin ceramic CQFP hermetic package and rated for military B-grade operation from –55°C to +125°C, with FuseLock security and mixed-voltage I/O support.
How Is the ACTEL A54SX72A-CQ208B Different From the A54SX72A-1CQ208B?
The primary difference is the speed grade. The ACTEL A54SX72A-CQ208B operates at the standard speed grade, while the A54SX72A-1CQ208B is tested and guaranteed to a higher maximum operating frequency of 217 MHz. Both share the same 72K gate die, ceramic CQFP package, and military B-grade temperature rating.
Is the ACTEL A54SX72A-CQ208B Re-Programmable?
No. The ACTEL A54SX72A-CQ208B uses one-time programmable antifuse technology. Once programmed, the device configuration is permanently fixed and cannot be erased or modified, providing maximum security and reliability for mission-critical defense applications.
What Security Features Does the ACTEL A54SX72A-CQ208B Offer?
The ACTEL A54SX72A-CQ208B features Actel’s FuseLock security technology, which permanently prevents internal probing and overwriting of the programmed design, making it suitable for classified and sensitive defense IP applications where design security is paramount.
How Do I Order the ACTEL A54SX72A-CQ208B?
You can submit an inquiry directly through our website contact form or email our sales team. We will respond with pricing, lead time, and availability within 24 hours for the ACTEL A54SX72A-CQ208B.
