ADI AD7476ABKSZ
- 12-bit SAR ADC with 1 MSPS throughput rate and internal track-and-hold amplifier
- SPI-compatible serial interface — CS and SCLK controlled, no pipeline delay
- Single 2.35V to 5.25V supply with VDD-referenced internal reference — no external reference required
- Power-down mode with 1 µA maximum standby current for power-sensitive applications
- 6-lead SC70 package — industry's smallest 12-bit ADC footprint at industrial temperature range
The ADI AD7476ABKSZ is the B-grade, 6-lead SC70 bulk-packed variant of the AD7476A — a 12-bit, 1 MSPS successive approximation ADC that achieves high throughput at extremely low power in the smallest available package for a 12-bit converter. Operating from a single 2.35V to 5.25V supply, it derives its reference directly from VDD, eliminating the external reference component and simplifying the supply design to a single decoupled rail. The track-and-hold amplifier handles input frequencies in excess of 13 MHz, and the conversion rate is determined entirely by the serial clock frequency — a design that allows the system to trade throughput for power consumption by reducing SCLK speed and using power-down mode between conversions.
The SC70 package of the AD7476ABKSZ — six leads in a 2.0 × 2.1 mm footprint — makes it the natural choice when board area is the binding constraint in a 12-bit ADC selection. Three-wire SPI interface with CS and SCLK controls the conversion directly: the input is sampled on the falling edge of CS, and conversion data clocks out MSB-first over SDATA with no pipeline delay. The B-grade specification provides ±1.5 LSB maximum INL — the same linearity as the standard A variant with tighter production testing, appropriate for designs where the ADC's linearity error is a significant contributor to the overall measurement accuracy budget. The ABKSZ suffix denotes bulk packaging in a cut tape strip rather than a reel, suited for prototype and low-volume procurement.
Related Products For Your Business
For procurement teams sourcing the AD7476ABKSZ, the combination of 6-lead SC70 packaging and 1 MSPS throughput at under 3 mW on a 5V supply defines its position in the ADC market: the smallest, lowest-power 12-bit SAR ADC with SPI interface in volume production. The ABKSZ suffix identifies bulk cut-tape packaging — the standard format for prototype and low-to-medium volume builds where reel quantities are excessive. The B-grade linearity specification provides ±1.5 LSB maximum INL with tighter production testing than the standard variant, appropriate for precision sensor interfaces where converter linearity contributes directly to measurement accuracy.
AD7476ABKSZ Architecture: VDD-Referenced SAR for Minimum External Components
The VDD-referenced internal reference is the feature that most reduces external component count in AD7476A-based designs. With no external reference required, the complete ADC circuit is the device itself plus supply decoupling — three signals connect to the processor (CS, SCLK, SDATA), and the full 0V to VDD input range is immediately usable. Power-down mode reduces standby current to 1 µA maximum by asserting CS high after conversion — the device powers back up within 1 µs when CS falls again, making the power-down/wake-up cycle compatible with throughput rates well below 1 MSPS without significant latency penalty. The serial clock flexibility means that any processor with an SPI port — including 3.3V and 5V microcontrollers, DSPs, and FPGAs — can interface directly without level translators when supply voltages are matched.
AD7476ABKSZ vs AD7476A Family: Package and Grade Selection
The AD7476A family offers three package options and two grade levels:
| AD7476ABKSZ | AD7476ABRMZ | AD7476AWYRMZ | |
|---|---|---|---|
| Package | 6-Lead SC70 | 8-Lead MSOP | 8-Lead MSOP |
| Grade | B (±1.5 LSB) | B (±1.5 LSB) | B (±1.5 LSB) |
| Temperature | –40°C to +85°C | –40°C to +85°C | –40°C to +125°C |
| Packaging | Bulk / Cut Tape | Tape and Reel | Tape and Reel |
| Best For | Smallest footprint, prototyping | SMT production, standard size | Extended temp, –40°C to +125°C |
The AD7476ABKSZ is the correct choice when minimum board area is the priority and the –40°C to +85°C industrial range is sufficient. For designs requiring operation beyond +85°C — defense avionics bays, engine compartments, or high-ambient industrial environments — the AD7476AWYRMZ extends the rating to +125°C in the same MSOP package. For production builds requiring tape and reel packaging in the SC70 footprint, the AD7476ABKSZ-500RL7 (500-unit reel) or AD7476ABKSZ-REEL7 (5000-unit reel) are the reel-packaged equivalents.
Sourcing the ADI AD7476ABKSZ
The AD7476ABKSZ is an active-production standard product with broad distribution availability. We carry verified inventory with full lot traceability and anti-counterfeit inspection on every order. Contact us today to confirm availability and request a quote — our team responds within 24 hours.
- ABKSZ suffix is bulk cut-tape — suited for prototype and low-to-medium volume procurement without reel minimum
- VDD-referenced internal reference eliminates external reference component entirely
- No pipeline delay — conversion result is available immediately after the 12th SCLK falling edge
- Power-down mode recovers in under 1 µs — enables sub-MSPS throughput with proportional power reduction
- Compatible with 3.3V and 5V SPI, QSPI, MICROWIRE, and DSP serial interfaces without level translation
- Reel-packaged equivalents available: AD7476ABKSZ-500RL7 (500 unit) and AD7476ABKSZ-REEL7 (5000 unit)
- Pin-compatible with AD7477ABKSZ (10-bit) and AD7478ABKSZ (8-bit) for resolution migration without layout changes
- Full lot traceability and anti-counterfeit inspection on every order
