ADI AD9154BCPZ

Four 16-bit DAC channels at 2.4 GSPS with integrated digital modulation and per-channel compensation on a JESD204B interface: the ADI AD9154BCPZ is the transmit DAC that removes the discrete signal processing chain from the direct conversion radar and EW transmitter design. For radar and electronic warfare programs where the transmit signal chain must synthesize complex wideband waveforms with controllable amplitude, phase, and frequency, the integrated digital modulation and compensation architecture of the AD9154 reduces the FPGA processing burden and eliminates the calibration software overhead that systems relying on analog compensation alone require. The BCPZ package variant without heat spreader fits designs where the PCB thermal design handles the DAC’s heat dissipation directly through the board.

AD9154BCPZ Architecture: TxDAC and Integrated Transmit Compensation

The TxDAC+ architecture underlying the AD9154 uses a current-segmentation switching topology optimized for spurious-free dynamic range at high output frequencies. The four DAC channels share a common JESD204B data link but each has independent gain, phase, and offset adjustment registers accessible via SPI, enabling correction of the I and Q channel imbalances that arise in analog quadrature modulators without iterative factory calibration. The per-channel power detector samples the input data stream and computes signal power in the digital domain, providing a metric for transmit power control loops that can respond to changes in the digital input without analog power detection hardware at the DAC output. Mix-Mode operation reconfigures the DAC output to reconstruct signals centered in the second or third Nyquist zone, extending the effective output frequency range for IF generation applications where the target carrier frequency exceeds the first Nyquist limit of the 2.4 GSPS sample rate.

AD9154BCPZ vs AD9154 Family and Related DACs: Selection Guide

The AD9154 family and its close relatives span a range of sample rates, channel counts, and integration levels for radar and EW transmit chain design:

The AD9154BCPZ is the correct selection for programs requiring a high-performance quad 16-bit DAC at 2.4 GSPS without the ADC cores and additional complexity of the AD9081BBPZ-4D4AC MxFE platform. The AD9154BCPZRL is the electrically identical reel-packaged variant for volume production. For programs that also need receive-path digitization on the same device, the AD9081 is the appropriate step up.

Sourcing the ADI AD9154BCPZ

The AD9154BCPZ is an active-production component with consistent demand across radar, EW, and wideband communications programs. We carry verified inventory with full lot traceability and anti-counterfeit inspection on every order. Contact us today to confirm availability and request a quote, and our team responds within 24 hours.

• BCPZ tray packaging suited for prototyping, qualification builds, and lower-volume production programs
• Mix-Mode extends IF generation to 2nd and 3rd Nyquist zones without additional hardware
• Per-channel power detection enables transmit power control without analog directional coupler hardware
• DAC outputs optimized for direct interface to ADRF672x analog quadrature modulators without external matching
• SPI read/write speeds up to 100 MHz support fast parameter updates in frequency-agile EW systems
• AD9154-EBZ, AD9154-M6720-EBZ, and AD9154-FMC-EBZ evaluation boards available for system development
• AD9154BCPZRL tape-and-reel variant available for high-volume production builds
• Full lot traceability and anti-counterfeit inspection on every order

Frequently Asked Questions (FAQ)

What Is the ADI AD9154BCPZ and How Does It Differ From the AD9154BCPZRL?

The AD9154BCPZ is a quad 16-bit 2.4 GSPS TxDAC+ with JESD204B interface, integrated digital modulation, per-channel compensation, and Mix-Mode, in an 88-lead LFCSP without heat spreader, packaged in trays. The AD9154BCPZRL is electrically identical but packaged in tape-and-reel format for automated SMT assembly in volume production. Choose BCPZ for prototype and qualification builds; choose BCPZRL for production volume builds.

What Is Mix-Mode and How Does It Extend the AD9154 Output Frequency Range?

Mix-Mode reconfigures the DAC output to reconstruct signals centered in the second or third Nyquist zone rather than the first. At a 2.4 GSPS sample rate, the first Nyquist zone extends from DC to 1.2 GHz. Mix-Mode allows carriers centered above 1.2 GHz to be synthesized directly from the DAC output without an analog upconversion stage, effectively doubling or tripling the frequency range available to the transmitter without increasing the sample rate.

How Does the AD9154BCPZ Compare to the AD9081BBPZ-4D4AC for Radar Transmit Applications?

The AD9081BBPZ-4D4AC integrates four 12 GSPS DAC cores, four 4 GSPS ADC cores, 48 DDCs, and 16 programmable FIR filters in a single 28 nm device, providing a complete transceiver at five times the DAC sample rate. The AD9154BCPZ provides four 2.4 GSPS DAC channels with deep transmit compensation but no receive path, suited for programs where the transmit and receive chains use separate devices or where 2.4 GSPS DAC performance is sufficient for the target frequency plan.

What FPGA Interface Does the AD9154BCPZ Require?

The AD9154BCPZ uses JESD204B Subclass 1 with up to eight serial lanes at rates up to 15 Gbps. Compatible FPGA platforms include Xilinx UltraScale and UltraScale+, Intel Arria and Stratix series, and Microsemi PolarFire. ADI provides HDL reference designs and evaluation board support through the ADS7-V2 capture platform.

How Do I Request a Quote for the ADI AD9154BCPZ?

Submit an inquiry through our website contact form or email our sales team directly. We will respond within 24 hours with pricing, availability, and lead time, and can discuss long-term supply agreements for radar and EW production programs.
