ALTERA EP4SGX230KF40I4N
- 230,000 logic elements with adaptive logic modules
- 6.7 Mbits of embedded memory including M9K and M144K blocks
- 16 full-duplex transceivers supporting up to 8.5 Gbps data rates
- Radiation-tolerant design compliant with aerospace industry standards
- Integrated high-speed serial interfaces and DSP blocks for signal processing
in demanding aerospace and defense applications like radar systems and electronic warfare, reliable high-performance processing is non-negotiable. The ALTERA EP4SGX230KF40I4N delivers the processing power and ruggedness required for these mission-critical environments. Its adaptive architecture balances logic density, memory bandwidth, and signal processing capabilities to handle complex algorithms and real-time data streams.
This Stratix IV GX FPGA combines radiation-hardened design features with high-speed connectivity, making it suitable for deployment in harsh space and airborne environments. The device's integrated transceivers and DSP blocks eliminate the need for external components, reducing system complexity while maintaining signal integrity. Engineers can leverage its flexible architecture to implement custom signal processing pipelines and communication protocols tailored to specific mission requirements.
Related Products For Your Business
The ALTERA EP4SGX230KF40I4N is a high-density, radiation-tolerant FPGA designed specifically for aerospace and defense applications requiring robust signal processing and high-speed connectivity. As a trusted EP4SGX230KF40I4N supplier, we offer competitive pricing and reliable availability for production and prototype orders. Contact our team to request a quote and check stock status for this critical component.
Core Technical Specifications
This Stratix IV GX device balances logic density with specialized signal processing capabilities. Its 230,000 logic elements and 512 DSP blocks enable implementation of complex radar signal processing algorithms, while 6.7 Mbits of embedded memory provides high-bandwidth data buffering for real-time applications. The integrated transceivers support high-speed data links between system components, reducing the need for external communication chips.
Military-Grade Performance & Reliability
Aerospace and defense applications demand components that can withstand extreme environmental conditions. The EP4SGX230KF40I4N is qualified to MIL-STD-883 standards and features radiation-hardened design to resist single-event effects (SEE) and total ionizing dose (TID) up to 30 krad(Si). This makes it suitable for deployment in satellite systems, airborne platforms, and ground-based defense equipment where failure is not an option.
Supply Chain & Quality Assurance
As a specialized FPGA supplier, we understand the critical nature of aerospace and defense components. We maintain strict quality control processes and provide full traceability documentation for all orders. Our team can assist with compliance verification and export documentation to ensure seamless integration into your supply chain. Contact us for pricing information and lead time estimates tailored to your project requirements.
- Supports partial reconfiguration for in-flight system updates
- Integrated clock management with 12 phase-locked loops (PLLs)
- Compliance with RTCA DO-254 for avionics software/hardware development
- JTAG boundary scan support for board-level testing
- Low-power design features for battery-operated applications
- Compatible with Quartus II design software for implementation and verification
- Offers built-in error correction code (ECC) for embedded memory blocks
- Supports multiple I/O standards including LVDS, LVPECL, and SSTL
EP4SGX230KF40I4N Frequently Asked Questions
What makes the EP4SGX230KF40I4N suitable for aerospace applications?
This FPGA features a radiation-tolerant design qualified to MIL-STD-883 standards, operating temperature range of -55°C to +125°C, and resistance to single-event effects (SEE), making it ideal for harsh aerospace environments.
What signal processing capabilities does this device offer?
With 512 DSP blocks (9×18 multipliers) and high-speed transceivers up to 8.5 Gbps, the EP4SGX230KF40I4N can implement complex signal processing pipelines for radar, electronic warfare, and communication systems.
What is the total embedded memory capacity?
The device provides 6.7 Mbits of embedded memory across 384 M9K blocks and 16 M144K blocks, supporting high-bandwidth data buffering and storage for real-time applications.
Does this FPGA support partial reconfiguration?
Yes, the EP4SGX230KF40I4N supports partial reconfiguration, allowing engineers to update specific portions of the design in-field without interrupting overall system operation.
What supply voltages are required?
The device uses a 1.0V core voltage with 1.8V/2.5V compatible I/O banks, supporting a wide range of interface standards and power system designs.
How do I obtain pricing and availability information?
As an EP4SGX230KF40I4N supplier, we offer customized pricing based on order volume and project requirements. Contact our sales team to request a quote and check current stock availability.
