ADI AD9689BBPZ-2000

14-bit resolution with 2.0 GSPS sampling rate
Wide input bandwidth supporting direct RF sampling
1.7V core supply voltage for low power operation
Hermetic BGA-196 package for harsh environments
MIL-STD-883 qualified for military applications

Inquire Now

High-speed analog-to-digital conversion is critical in modern defense and aerospace systems, where capturing wideband RF signals with precision can mean the difference between mission success and failure. The ADI AD9689BBPZ-2000 addresses this need with its exceptional sampling rate and wide input bandwidth, designed specifically for applications requiring rapid signal processing.

This converter combines high performance with robust military-grade construction, making it suitable for deployment in challenging environments. Its hermetic packaging ensures reliable operation under extreme temperatures and mechanical stress, while its low power profile helps reduce overall system energy requirements.

Category	Parameter	Value
Core Performance	Resolution	14 bits
	Sampling Rate	2.0 GSPS
	Input Bandwidth	>9 GHz
Electrical Characteristics	Core Supply Voltage	1.7V
	Analog Input Range	1V p-p differential
	SNR (Typical)	68.5 dBFS
	SFDR (Typical)	82 dBc
Operating Conditions	Temperature Range	-55°C to +125°C
	Qualification Standard	MIL-STD-883 Class B
Package	Type	Hermetic BGA-196
	Packaging	Tape and Reel

Related Products For Your Business

AIRBORN RM322-059-221-2900

ADI 5962-8876401LA

ACTEL MPF300T-1FCG484I

ATMEL AT28C256-15DM/883

The ADI AD9689BBPZ-2000 is a high-performance, military-grade 14-bit analog-to-digital converter designed for demanding defense and aerospace applications. With its 2.0 GSPS sampling rate and wide input bandwidth, this ADC delivers the speed and precision needed to capture and process complex RF signals in real time. As a specialized AD9689BBPZ-2000 supplier, we understand the critical role this component plays in mission-critical systems, and we’re committed to providing competitive pricing and reliable availability for our customers.

Core Technical Specifications

At the heart of the AD9689BBPZ-2000 is its exceptional signal conversion capability. The 14-bit resolution ensures accurate representation of analog signals, while the 2.0 GSPS sampling rate enables capture of fast-changing waveforms with minimal distortion. The device’s wide input bandwidth supports direct RF sampling up to 9 GHz, eliminating the need for intermediate frequency stages in many applications.

Military-Grade Performance & Reliability

Built to meet MIL-STD-883 Class B specifications, this ADC undergoes rigorous screening to ensure reliability in harsh environments. Its hermetic BGA-196 package provides protection against moisture, dust, and mechanical shock, while its extended operating temperature range of -55°C to +125°C makes it suitable for deployment in extreme conditions. Whether used in radar systems, electronic warfare platforms, or satellite communications, the AD9689BBPZ-2000 delivers consistent performance when it matters most.

Supply Chain & Quality Assurance

As a trusted AD9689BBPZ-2000 supplier, we offer comprehensive supply chain support, including full traceability and anti-counterfeit measures. Our inventory includes products in stock with competitive lead times, and we provide detailed documentation to ensure compliance with military and industrial quality standards. Contact our team to request a quote or check availability for your specific application requirements.

Direct RF sampling capability eliminates external downconversion stages
Low power operation reduces overall system energy consumption
MIL-STD-883 Class B qualification ensures military-grade reliability
Hermetic packaging provides enhanced protection in harsh environments

14-bit resolution balances precision and system complexityWide input bandwidth supports diverse signal processing applicationsHigh sampling rate enables real-time signal capture and analysisComprehensive screening and testing ensure long-term reliability

When you need a high-speed ADC that combines military-grade durability with exceptional performance, the ADI AD9689BBPZ-2000 is an ideal choice. Contact our team today to discuss your requirements, request pricing information, or place an order.

AD9689BBPZ-2000 Frequently Asked Questions

What is the sampling rate of the AD9689BBPZ-2000?

The AD9689BBPZ-2000 features a maximum sampling rate of 2.0 GSPS, enabling capture of high-frequency signals with exceptional detail.

What military standards does this ADC comply with?

This device is qualified to MIL-STD-883 Class B standards, ensuring it meets rigorous military reliability and performance requirements.

What package type is used for the AD9689BBPZ-2000?

The AD9689BBPZ-2000 comes in a hermetic BGA-196 package, designed for reliable operation in harsh environmental conditions.

What is the operating temperature range?

This military-grade ADC operates reliably across a temperature range of -55°C to +125°C, suitable for extreme environment deployment.

Can I get technical support for this product?

Yes, our team of technical experts provides comprehensive support for product selection, application design, and troubleshooting.

How do I request pricing or check availability?

Contact our sales team directly to request a quote, check current stock availability, or discuss volume pricing options for the AD9689BBPZ-2000.

ADI AD9689BBPZ-2000
