ADI HMC-APH596
- 16 to 33 GHz frequency coverage for wideband applications
- +33 dBm output IP3 for linear signal amplification
- +24 dBm P1dB for reliable power delivery
- 17 dB small-signal gain with flat response
- +5V single-supply operation for simplified integration
Radar and electronic warfare systems demand amplifiers that deliver consistent performance across wide frequency bands while maintaining linearity and efficiency. The ADI HMC-APH596 addresses these needs with its GaAs HEMT MMIC design, optimized for operation from 16 to 33 GHz. This two-stage amplifier provides the high output power and linearity required for modern aerospace and defense applications. Built with robust materials and manufacturing processes, the HMC-APH596 features fully matched 50 Ω input and output ports, eliminating the need for external matching networks in most designs. Its compact die form factor makes it suitable for integration into high-density RF assemblies, while its single +5V supply simplifies power system design. The device's passivated surface and hermetic construction ensure reliable operation in harsh environmental conditions typically encountered in aerospace missions.
Related Products For Your Business
The ADI HMC-APH596 is a high-performance medium power amplifier designed to meet the demanding requirements of aerospace and defense applications. Operating across the 16 to 33 GHz frequency range, this GaAs HEMT MMIC delivers exceptional linearity and power efficiency, making it an ideal solution for radar, electronic warfare, and satellite communication systems. As a specialized HMC-APH596 supplier, we offer competitive pricing and reliable supply chain support for production orders.
Core Technical Specifications
The HMC-APH596 combines broadband frequency coverage with robust power performance in a compact die package. Its 17 dB typical gain provides sufficient signal amplification for most RF front-end designs, while the +33 dBm output IP3 ensures minimal signal distortion even under high-power conditions. The device’s single +5V supply simplifies system integration and reduces overall power consumption compared to dual-supply alternatives. For engineers evaluating components, the HMC-APH596 offers a compelling balance of performance and ease of use. Contact our team for detailed technical specifications and to request a quote.
Military-Grade Performance & Reliability
Built to withstand the harsh environmental conditions of aerospace and defense applications, the HMC-APH596 features a passivated GaAs HEMT MMIC design with hermetic construction. This ensures reliable operation under extreme temperatures, vibration, and radiation exposure typically encountered in airborne and spaceborne systems. Compared to commercial-grade amplifiers, the HMC-APH596 undergoes rigorous screening processes to meet aerospace quality standards, providing the long-term reliability critical for mission-critical applications. When comparing alternatives, consider the HMC-APH596 alongside products like the ADA4077-2BRZ for low-frequency applications, or high-speed ADCs such as the AD9689BBPZ-2000 for complete signal chain solutions.
Supply Chain & Quality Assurance
As a trusted supplier of aerospace-grade components, we understand the importance of reliable supply chains and traceable documentation. The HMC-APH596 is available with full traceability from the manufacturer, including certificates of conformance and test reports. We maintain inventory of critical components to support both prototype development and full-scale production, with flexible lead times to meet project schedules. Our team can provide competitive pricing information and assist with export compliance documentation for international shipments. Check stock availability and request a quote to begin your integration process.
When selecting components for aerospace and defense applications, performance and reliability are non-negotiable. The ADI HMC-APH596 delivers on both fronts, providing the broadband performance and linearity required for modern RF systems. Contact our technical support team to discuss your specific application requirements and learn how the HMC-APH596 can enhance your design.
- GaAs HEMT MMIC technology ensures high efficiency and linearity
- 50 Ω matched input/output simplifies system integration
- Compact die form factor ideal for high-density assemblies
- Single +5V supply reduces power system complexity
- Passivated surface enhances environmental robustness
- Suitable for both airborne and spaceborne applications
- Fully compatible with standard die attach and wire bonding processes
- RoHS compliant for environmental responsibility
HMC-APH596 Frequently Asked Questions
What is the typical gain of the HMC-APH596?
The HMC-APH596 provides a typical small-signal gain of 17 dB across its 16 to 33 GHz frequency range, with a flat response suitable for wideband applications.
What supply voltage does the HMC-APH596 require?
This amplifier operates from a single +5V supply, simplifying power system design and reducing overall component count in RF assemblies.
What is the output power capability of the HMC-APH596?
The device delivers a typical P1dB compression point of +24 dBm and an output IP3 of +33 dBm, providing linear amplification for high-power signal applications.
What package type is available for the HMC-APH596?
The HMC-APH596 is supplied in a bare die format, with dimensions of 2.55 x 1.87 x 0.1 mm, suitable for die attach processes in hybrid microcircuits and multi-chip modules.
What environmental qualifications does the HMC-APH596 meet?
This amplifier is qualified for aerospace applications, with typical operating temperature range of -40°C to +85°C and compliance with standard military screening processes.
How does the HMC-APH596 compare to other ADI amplifiers?
For lower frequency applications, consider the ADA4077-2BRZ operational amplifier, while high-speed ADCs like the AD9694BCPZ-500 can complement the HMC-APH596 in complete signal chain solutions. Contact our team for detailed application comparisons.
